Universal Strength Machine
The Universal Strength Machine VUD is a versatile device designed to measure multiple strength parameters, including compression, tensile, transverse, twin transverse, and high dry strength. IoT-enabled for remote monitoring and data collection, it offers exceptional precision and reliability—making it an ideal solution for laboratories requiring comprehensive strength testing capabilities.
The Universal Strength Machine features a loading and sensing system controlled via a microcontroller or PLC, with results displayed on an LCD screen. By default, it measures the compression strength of standard AFS specimens (2”×2”) or Metric specimens (50 mm × 50 mm).
Universal Strength Machine by Versatile
With the appropriate attachments, the machine can also measure:
- High Compression Strength (see 4.2.1)
-
Shear Strength (see 4.2.2)
-
Splitting Strength (see 4.2.3)
-
Tensile Strength (see 4.2.4)
-
Transverse Strength (see 4.2.5)
-
Twin Transverse Strength (see 4.2.6)
-
Deformation (see 4.2.7)
